| DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.05%+3) |
| AC Voltage |
2V/20V/6V/200V/750V |
±(0.5%+10) |
| Resistance |
2Ω/20Ω/200Ω/2kΩ/200kΩ |
±(0.5%+3) |
|
2MΩ/20MΩ/60MΩ |
±(1.0%+10) |
| Capacitance |
200pF/2nF/20nF/200nF |
±(5.0%+20) |
|
2μF/20μF/200μF |
±(2.0%+5) |
|
2mF/60mF |
±(5.0%+5) |
| Diode Test |
Available |
— |
| Continuity Test |
Buzzer sounds when resistance ＜30Ω |
— |
| Frequency |
Direct reading 1~1000Hz via ACV gear |
±(1.0%+2) |
| Variable-frequency Voltage |
Frequency range:30~1000Hz |
— |
| LED/IGBT Test |
Gear output: DC 25V, 0.1mA |
— |
| Low Resistance(200mA) |
0~200Ω; for precise testing of coil & motor resistance |
±(1.0%+3) |
| Power Source |
6×AAA 1.5V batteries |
— |
| Max Display Count |
19999 |
— |
| Sampling Rate |
3 readings/second |
— |
| True RMS |
Yes |
— |
| Relative Measurement |
Available |
— |
| Data Hold |
Available |
— |
| Backlit Display |
Available |
— |
| Meter Dimensions |
215×95×55mm |
— |
| Net Weight(Main Unit) |
550g |
— |
